Lab Name : Applied Mechanics Lab
| Sr. No. | Entity | Details |
|---|---|---|
| 1 | Area of Laboratory | 80 sq.m |
| 2 | Name of Lab In charge | Mr. Waghmode A.U. |
Laboratory Major Equipment Details :
| Sr. No. | Name of equipment |
|---|---|
| 1 | Differential Axle & Wheel |
| 2 | Single Purchase Crab |
| 3 | Weston’s Differential Pulley Block |
| 4 | Simple Screw Jack |
| 5 | Lami’s theorem |
| 6 | Verify equilibrium of parallel forces |
| 7 | Simple supported beam |
Photos of Laboratory :
Lab Name : Computer Aided Drawing Lab
| Sr. No. | Entity | Details |
|---|---|---|
| 1 | Area of Laboratory | 78 sq.m |
| 2 | Name of Lab In charge | Mr.Kamble P.S. |
Laboratory Major Equipment Details :
| Sr. No. | Name of equipment |
|---|---|
| 1 | 2.8 GHz Dual Core (ist Gen.),2GB RAM 250GB HDD,15.6” AOC Monitor, Keyboard ,Mouse |
| 2 | Mini laptop Samsung |
| 3 | Projector Espon EB-S02 |
| 4 | HP Laser Printer 1108 |
Photos of Laboratory :
Lab Name : Material Testing Lab
| Sr. No. | Entity | Details |
|---|---|---|
| 1 | Area of Laboratory | 118 sq.m |
| 2 | Name of Lab In charge | Mr.Bhosale M.S. |
Laboratory Major Equipment Details :
| Sr. No. | Name of equipment |
|---|---|
| 1 | Universal Testing Machine Model UTE 100T |
| 2 | Impact Testing Machine IT-30 and Izod impact testing machine |
| 3 | Hardness Testing Machine |
| 4 | Tile Flexure Strength Testing Machine |
| 5 | Tile Abrasion Testing Machine |
| 6 | Torsion Testing Machine |
Photos of Laboratory :
Lab Name : Surveying Lab
| Sr. No. | Entity | Details |
|---|---|---|
| 1 | Area of Laboratory | 78 sq.m |
| 2 | Name of Lab In charge | Mr.Kamble P.S. |
Laboratory Major Equipment Details :
| Sr. No. | Name of equipment |
|---|---|
| 1 | Auto Level |
| 2 | Planimeter (Digital) |
| 3 | Plane table with all standard accessories |
| 4 | Nautical sextant |
| 5 | Global positioning system (GPS) |
| 6 | Total station with all accessories |
| 7 | Tacheometer |
| 8 | Telescopic alidade |
| 9 | Dumpy level |
Photos of Laboratory :
Lab Name : Concrete Technology Lab
| Sr. No. | Entity | Details |
|---|---|---|
| 1 | Area of Laboratory | 118 sq.m |
| 2 | Name of Lab In charge | Mr. Pawar S.K. |
Laboratory Major Equipment Details :
| Sr. No. | Name of equipment |
|---|---|
| 1 | Flow table (small) hand operate |
| 2 | Vee-Bee Apparatus |
| 3 | Different types IS sieve G.I frame 300 mm dia. From 100 mm to 4.75 mm(15 PCS) |
| 4 | Needle vibrator |
| 5 | Humidifier |
| 6 | Vibrating table |
| 7 | 200 KN compressive testing machine |
| 8 | Flow table (big) hand operate |
| 9 | Concrete test hammer |
| 10 | Oven, thermostatic 45x45x45 cm |
| 11 | Water bath 30x25x12.5 cm |
| 12 | Vibration machine |
| 13 | Electronic balance 100 kg |
| 14 | Electronic balance 6 kg |
| 15 | Concrete permeability machine (three cell) without compressor |
| 16 | Concrete mixer |
| 17 | Steel measuring cylinder (3L,15L,30L) |
Photos of Laboratory :
Lab Name : Transportation Engineering Lab
| Sr. No. | Entity | Details |
|---|---|---|
| 1 | Area of Laboratory | 81 sq.m |
| 2 | Name of Lab In charge | Mr.Mule V.V. |
Laboratory Major Equipment Details :
| Sr. No. | Name of equipment |
|---|---|
| 1 | Flash Point (Closed) Pensky-Marten apparatus, IS: 1209. IS:1448 with energy regulator |
| 2 | Universal Penetrometer with in-built timer, IS:1448 (pt-60) IS:1203 |
| 3 | Standard Tar Viscometer, Electrically Heated with 10mm Cup and valve, IS: 1206, IP: 72, supplied with dimmerstat. |
| 4 | Marshall apparatus ,Single Speed, with dial gauge & 50 kN capacity Proving ring |
| 5 | Ring & Ball apparatus, Electrically heated, IS:1205 |
| 6 | Ductility Testing machine, electrically operated, IS 1208, with Digital temp controller |
| 7 | Benkelman Beam, with Digital dial gauge 0.01 x 25mm |
| 8 | Aggregate Impact Tester with blow counter,b(Pt.IV) |
| 9 | Aggregate crushing value apparatus,IS:2386, 150mm dia. Steel cylindrical, plunger and base plate, tamping rod & metal measure |
| 10 | Los Angles Abrasion testing machine IS:2386(pt-IV), with abrasive charge |
| 11 | Sieve Shaker, Motorised |
| 12 | Adaptor for 30cm dia. sieves |
| 13 | C.B.R. Test apparatus, Motorised, three speed, with Proving ring and dial gauge IS:9669-1980, IS:2720 (Pt. XV), with mould , perporated base plate collar are of zinc plate mild steel |
| 14 | C.B.R. Mould, Gun metal, 150mm internal dia. & 175mm high |
| 15 | Perforated base plate,gun metal for above mould |
| 16 | Thermostatic Laboratory Oven Internal Size: 45cm x 45cm x 45cm |
Photos of Laboratory :
Lab Name : Geotechnical Engineering Lab
| Sr. No. | Entity | Details |
|---|---|---|
| 1 | Area of Laboratory | 81 sq.m |
| 2 | Name of Lab In charge | Miss.Nirali P.R. |
Laboratory Major Equipment Details :
| Sr. No. | Name of equipment |
|---|---|
| 1 | Sampler Extractor, Hand operated, for38mm dia.specimen |
| 2 | Riffle Sampler Divider, as per IS:1677-1960, IS:2720 (pt.IV) with three container Size:14 chutes,13 mm size |
| 3 | Riffle Sampler Divider, as per IS:1677-1960, IS:2720 (pt.IV) with three container Size:16 chutes,16 mm size |
| 4 | Universal Extractor frame |
| 5 | Thermostatic Laboratory Oven. |
| 6 | Liquid Limit Device |
| 7 | Cone Penetrometer Digital |
| 8 | Shrinkage Limit kit set with 750gm mercury |
| 9 | Sieve Shaker, Motorised, with built in Digital timer |
| 10 | Unconfined Compression tester |
| 11 | Sample Extractor, Hand operated for 38mm dia. Specimens for Unconfined compression test or Tri axial shear test |
| 12 | Triaxial outfit , motorized with electronic sensors |
| 13 | Direct Shear test apparatus |
| 14 | Laboratory Vane Shear |
| 15 | Compaction test apparatus, Heavy duty. |
| 16 | C.B.R. Test apparatus |
Photos of Laboratory :
